Manufacturer: ERBEND Model:MFC 3215

Manufacturer

Erbend

Stock

120633

Model

MFC 3215

Dealer Location

Utah

Spec Sheet

Max Thickness 0.059"
Overall Length 10.5'
Sheet Length 3200
Steel 1.5
Stainless 1
Aluminum 2
Dimensions 4450 / 2100 / 1860 mm
Weight 3300 kgs
7" open height upper beam
Eccentric upper beam power transmission system
10&25 mm wide single piece folding tools as 2 sets
ERFOLD BASIC CNC LBL software on touchscreen with swivel arm
750 mm servo backgauge system with feather grooves
0-150° folding angle
Manual folding beam adjustment
Front light barriers
Solid lower beam tool without channels
