Heim 45-10 Flanged Bed Mechanical Press Brake #7565

Stock

7565

Model

45-10

Dealer Location

California

Spec Sheet

Overview

Type:
BRAKES- PRESS, MECHANICAL
Manufacturer:
HEIM
Model:
45-10
Stock #:
7565
Status:
For Sale
Serial #:
H3919
Country:
United States

Description

Explore the Heim 45-10 Flanged Bed Press Brake, designed for precision and power with features such as a 45-ton capacity, 10-foot bed, 2 HP motor, and PLC control. Ideal for enhancing your production line with its robust build and reliable performance.

Tonnage45 T40.823 t
TypeMECHMECH
Overall Length10'3 m
Between Housings110"2.8 m
Stroke2"50.8 mm

GENERAL SPECIFICATIONS:
Removable Flanged Bed and Ram
Tonnage, Near Bottom: 45
Tonnage, Mid Stroke: 30
Bed Size: 14" x 126"
Ram Size: 12" x 126"
Distance Between Housings: 110"
Stroke: 2"
Shut Height: 12"
Ram Adjustment: 2-1/2"
Strokes Per Minute: 40

EQUIPPED WITH:
2 HP Motor
Pedestal Control w/Dual Palm Buttons
PLC Control
Air Clutch
Power Ram Adjustment
(2) Air Counterbalances
Bijur Automatic Lubrication
Holes On Flanged Bed and Ram On 18" Centers

Approximate Weight: 7500 Lbs.
