ASTRO AVB-24-2-70 - Broache

Manufacturer

ASTRO

Category

Broaches

Type

BROACHES, VERTICAL, SURFACE, (Single Ram)

Stock

14669

Model

AVB-24-2-70

Dealer Location

Michigan

Request a Quote
Login to Access Additional Features
View Contact Information

Spec Sheet

Highlights:
  • Allen Bradley Mini PLC-2/02 Programmable Controller
  • Hydraulic Unit
  • Vibratory Bowl Feeder
  • Floor Standing
  • Trabon Lubrication
  • Vickers Hydraulics
  • Heat Exchanger
  • Tooled For Last Job-7/16" Round 1" Long Steel Part
  • 15 HP General Electric 220/440 Volt Motor
  • Two .001 Dial Indicators on Tooling Set
,

Machine Specifications :

  • Year 1990
  • Manufacturer ASTRO
  • Stroke 24.0"
  • Tonnage 2.0
,

MODEL AVB-24-2-70 ASTRO 2 TON VERTICAL HIGH SPEED SURFACE BROACH

    Specifications:

  • Ton: 2
  • Stroke: 24"
  • Ram Travel: 2"-26"
  • Cutting Speed: 0-70 fpm
  • Return Speed: 140 fpm
  • Slide Width: 4"
  • Slide Length: 36"
  • Table R to L: 20" F to B 15"
  • Coolant Capacity: 20 Gallons
  • Oil Reservoir: 100 Gallons
  • Machine Dimensions:
  • Length: 82"
  • Width: 64"
  • Height: 115"
  • Net Weight (Approx.): 3,000 lbs
