HOFLER HELIX 400 - Gear Grinder

Manufacturer

HOFLER

Category

Gear Machines

Type

GEAR GRINDERS, CNC

Stock

25509

Model

HELIX 400

Dealer Location

Michigan

Request a Quote
Login to Access Additional Features
View Contact Information

Spec Sheet

Machine Specifications :

  • Year
  • Manufacturer HOFLER
  • Profile Grinding YES
  • Internal Grinding YES
  • Workpiece Diameter (max.) 15.7"
  • Distance Between Center Above Table (min.) 12.8"
  • Distance Between Center Above Table (max.) 29.3"
  • Module 0.5 - 15
  • Swivel Angle (max.) 45.0
  • Grinding Wheel Diameter (min.) 6.9"
  • Grinding Wheel Diameter (max.) 15.7"
  • Grinding Wheel Width (max.) 1.8"
  • Table Diameter 7.1"
  • Table Load (max.) 100.0
  • Table Hole Diameter 3"
  • Table Hole Depth 1.6"
  • Table Rotation Speed (max.) 85 RPM
,

The HELIX 400 cylindrical gear grinding machine is a compact, flexible profile grinding machine for workpiece diameters of up to 400 mm. Its well-engineered mechanical system makes it a reliable partner for precision manufacturing. The innovative control and software functions are also ideal for manufacturing special profile and tooth trace modifications for special series.

    Specifications:

  • Maximum Outside Diameter Toothed Gear: 400 mm
  • Minimum Toothed Gear Root Circle Diameter: 10 mm
  • Axial Stroke Length: 260 mm
  • Minimum-Maximum Distance Between Centers Over Table: 325 - 745 mm
  • Maximum Profile Height: 35 mm
  • Minimum-Maximum Module: 0.5 - Approximately 15
  • Swiveling Angle: +/- 45 Degrees
  • Maximum Grinding Wheel Diameter: 400 mm
  • Minimum Grinding Wheel Diameter: 174 mm
  • Maximum Grinding Wheel Width: 45 mm
  • Maximum Grinding Wheel Spindle Drive: 15 kW
  • Maximum Tool Slide Stroke Speed: 6 m/min
  • Table Diameter: 180 mm
  • Maximum Table Load: 100 kg
  • Table Hole (Diameter x Depth): 75 x 40 mm
  • Maximum Table Speed: 85 rpm
  • Approximate Machine Dimensions (LxWxH): 4,600 x 5,100 x 2,700 mm
  • Net Weight, Approximate: 10,000 kg
