18" x 27" HEM Model F130HA-DC Automatic Horizontal Band Saw, Double Column, 1.5" Blade, Bundling Vises, 72" Feed, 10 HP, 1996

Manufacturer

HEM

Category

Saws

Type

SAWS, BAND, HORIZONTAL

Stock

20081

Model

F130HA-DC

Dealer Location

Illinois

Request a Quote
Login to Access Additional Features
View Contact Information

Spec Sheet

18" x 27" HEM #F130HA-DC DOUBLE COLUMN PROGRAMMABLE AUTOMATIC
HORIZONTAL BAND SAW
S/N 495896 NEW 1996

CAPACITY --- ( ROUND ) -------------------- 18" DIAMETER
CAPACITY --- ( RECTANGULAR ) --------- 18" X 27"
VISE SHUTTLE STROKE -------------------- 0 TO 72"
BLADE SIZE ------------------------------------- 1.5" X .050" THICK X 22'2" LONG
BLADE SPEEDS -------------------------------- 80 TO 400 FPM
MAIN DRIVE MOTOR -------------------------- 10 HP AC
HYDRAULIC MOTOR -------------------------- 2 HP A.C.
APPROXIMATE MACHINE WEIGHT ------- 8,500 LBS

EQUIPPED WITH ---

2 HYDRAULIC VISES POWERED MOVEABLE GUIDE ARM
OPTIONAL 3RD HYDRAULIC VISE ON FEED TABLE POWERED LENGTH POSITIONER
COMPUTER CONTROLLED FEED SYSTEM POWERED BLADE TENSION
DOUBLE COLUMN (2) HYDRAULIC BUNDLING VISES
CUT WATCHER BLADE MONITOR SYSTEM VARIABLE BLADE SPEED
TOP CLAMP FOR BUNDLING DISCHARGE TABLE
MULTIPLE INDEX COOLANT SYSTEM
OPTIONAL 72" BAR FEED STROKE FULL STROKE VISES
HYDRAULIC UNIT CHIP AUGER
CANTED HEAD, 2 DEGREE TILT
