2 HP BRIDGEPORT Vertical Mill, Series I, 9" x 42" Table, Power Table Feed

Manufacturer

BRIDGEPORT

Category

Milling Machines

Type

MILLERS, VERTICAL

Stock

60696

Model

SERIES I

Dealer Location

Illinois

Request a Quote
Login to Access Additional Features
View Contact Information

Spec Sheet

2 HP BRIDGEPORT SERIES 1 VERTICAL MILL
S/N 195203 NEW 1979

SURFACE AREA OF WORK TABLE ---------------- 9" X 42"
TABLE TRAVEL --------------- ( X AXIS ) ------------ 28" LONGITUDINAL
SADDLE TRAVEL ------------ ( Y AXIS ) ------------ 12" CROSS
SPINDLE QUILL TRAVEL -- ( Z AXIS ) ------------ 5"
KNEE TRAVEL ------------------------------------------ 16" VERTICAL
SPINDLE SPEEDS, VARIABLE -------------------- 60 TO 4200 RPM
SPINDLE TAPER -------------------------------------- R-8
HEAD TILT FRONT TO BACK --------------------- +/- 45 DEG.
HEAD TILT SIDE TO SIDE ------------------------- +/- 90 DEG.
MAIN DRIVE MOTOR ------------------------------- 2 HP
PRESENT ELECTRICAL ARRANGEMENT --- 240/3/60
APPROXIMATE MACHINE WEIGHT ----------- 2,400 LBS

EQUIPPED WITH ---

VARIABLE SPEED
LONGITUDINAL POWER FEED TO TABLE
R-8 COLLETS
DRAW BAR
BIJUR ONE SHOT LUBRICATION
WORK LIGHT

NOTE: PICTURE SHOWING DIGITAL READOUT ( NOT WORKING )
