SHARP LMV/DVS, 9" x 42" Table, D.R.O., Digital Vari-Speed, 3 HP, 2008

Manufacturer

SHARP

Category

Milling Machines

Type

MILLERS, VERTICAL

Stock

60697

Model

LMV/DVS

Dealer Location

Illinois

Request a Quote
Login to Access Additional Features
View Contact Information

Spec Sheet

SHARP MODEL LMV/DVS KNEE TYPE VERTICAL MILL:
S/N 70330601 NEW 2008

GENERAL SPECIFICATIONS:
WORKING SURFACE OF TABLE --------------------- 9" X 42"
T-SLOTS, (NUMBER) SIZE ----------------- (3) --------5/8"
LONG. TRAVEL OF TABLE ----------------------------- 30"
CROSS TRAVEL OF SADDLE ------------------------- 12"
KNEE TRAVEL --------------------------------------------- 16"
RAM TRAVEL ---------------------------------------------- 12"
SPINDLE CENTER TO COLUMN (MIN./MAX/) --- 6-3/4" - 18-1/2"
SPINDLE NOSE TO TABLE (MIN./MAX/) ----------- 2-1/8" - 18"

HEAD:
SWIVEL - LEFT AND RIGHT -------------------------- +/- 45 DEGREES
TILT - FRONT TO BACK ------------------------------- +/- 45 DEGREES

QUILL:
DIAMETER (CHROMED) ------------------------------ 3-3/8"
TRAVEL ----------------------------------------------------- 5"
POWER FEEDS, IN./REV. ----------------------------- 0.0015, 0.003, 0.006

SPINDLE:
TAPER ----------------------------------------------------- R8
MOTOR, 230V/460V/60 HZ./3 PH. ----------------- 3 HP
SPEEDS, INFINITELY VARIABLE
BACK GEARED (LOW) ----------------------------- 60-500 RPM
DIRECT (HIGH) -------------------------------------- 500-4500 RPM
APPROXIMATE MACHINE WEIGHT ------------ 2,400 LBS
APPROXIMATE MACHINE DIMENSIONS ----- 71"(LR) X 63"(FB) X 81"(H)

EQUIPPED WITH ---

ACCURITE DIGITAL READOUT
DIGITAL VARIABLE SPEED (DVS)
DOUBLE FAN COOLING SYSTEM IN HEAD
ONE SHOT LUBE
FRONT AND REAR SADDLE WAY COVERS
CHROMED TABLE, SADDLE WAYS & GIBBS
MEEHANITE CASTINGS
R-8 COLLETS
MILLING VISE

NOTE: LONGITUDINAL POWER FEED TABLE WORKS INTERMITTENTLY.
