GLEASON 104 - Straight Bevel Gear Generator

Manufacturer

GLEASON

Category

Gear Machines

Type

GEAR GENERATORS, BEVEL, STRAIGHT

Stock

25876

Model

104

Dealer Location

Michigan

Request a Quote
Login to Access Additional Features
View Contact Information

Spec Sheet

Highlights:
  • Coniflex
  • Change Gears
  • Cutter Adapters
  • Cutters
  • Coolant Pump
  • Hydraulic Chucking
  • Hydraulic System
  • Lube System
  • Work Holding
  • Gages
,

Machine Specifications :

  • Year 1956
  • Manufacturer GLEASON
  • Maximum Face Width 1.375"
  • Diametral Pitch 3.0
  • Maximum Cone Distance 4.25"
  • Extreme Ratio 101.0
  • Control Manufacturer Conventional
  • Type Straight Bevel Coniflex Generator
  • Maximum Workpiece Diameter 9.82"
  • Maximum Face Width 1.375"
  • Diametral Pitch 0.0
  • Maximum Cone Distance 4.5"
  • Extreme Ratio 10.0
  • Number of Teeth 0.0
  • Control Manufacturer Conventional
,

The Gleason Model 104 Straight Bevel "Coniflex" Gear Generator is an industrial machine tool designed to produce high-precision straight bevel gears and pinions. It is renowned for manufacturing gears with localized, crowned tooth profiles (Coniflex), which prevent stress concentrations at the edges of the teeth and allow for smoother, more forgiving meshing.

    Specifications:

  • Cone Distance: 0 to 4-1/2"
  • Pitch Angle: 84 deg. 18 min. (max); 5 deg. 42 min. (min)
  • Extreme Ratio: 10-to-1
  • Pitch Diameter: 10-to-1 ratio; 8-1/2" (max)
  • Pitch Diameter: 1-to-1 ratio; 6" (max)
  • Diametral Pitch (coarsest): 3 DP
  • Diametral Pitch (finest): 20 DP
  • Face Width: 1-3/8" (max)
  • Index Range: 9 to 93 inclusive, and most numbers up to 175
  • Pressure Angles: 20, 22-1/2 & 25 deg.
  • Diameter of Taper Hole at Large : 3-29/32"
  • Taper per Foot: 39/64"
  • Depth of Taper: 6"
  • Diameter of Hole Through: 2-7/16"
  • Spindle Nose to Machine Center: 1-1/2" to 9"
  • Cutter Speeds: 98 to 286 (feet per minute)
  • Feeds: 4.2 to 69.2 (seconds per tooth)
  • Main Motor: 5 HP - 480V - 1800 RPM - 60 Hz - 3 PH
  • Hydraulic Pump Motor: 3/4 HP, 1800 RPM
  • Cutting Oil Pump Motor: 1/2 HP, 3600 RPM
  • Floor Space: 61-1/4" x 84-3/4"
  • Net Weight: 14,500#
