3″ Eaton Leonard VB300HP CNC Tube Bender

Manufacturer

Eaton Leonard

Category

Benders

Stock

163260021

Model

VB300HP

Dealer Location

Georgia

Spec Sheet

  • Stock #: 163260021
  • Brand: Eaton Leonard
  • Model: VB300HP
  • Capacity: 3.00 inches
  • Location: OH
  • Loading Fee: Free Loading

Specifications

  • Minimum Tube OD: 1/4″ OD
  • Maximum Tube OD: 3” OD x .125″ WT
  • Maximum Bending Angle: 195°
  • Maximum Bend Centerline Radius: 12”
  • Maximum Tube Length Over Mandrel: 144″
  • Bending Rotation: Left hand (Counter-clockwise)

Equipped With

Bendpro G2 Control System, Hydraulic Mandrel Extractor, Hydraulic Pressure Die Assist, Direct Acting Pressure Die, Drop Away Style Clamp Die, Pneumatic Collet Closer, Automatic Lubrication System, Hydraulic Oil Heat Exchanger – Fan Type, Vickers Hydraulic Valves, Programmable Pressure Controls On Pd And Pressure Die Assist, Carriage Kicker For Bending Non-Round Tubes

Additional Info

This machine can be inspected under power upon request.
