Lot 60: Agathon 175-DIA High Precision Carbide Tool Grinder, with Multi Angle Swivel Heads
Equipped With:

Precision Controls: Features a high-precision micrometer infeed mechanism and universal tool-holding fixture that can tilt, swivel, and rotate for exact angle adjustments. Coolant System: Integrated built-in coolant/oil pump and reservoir located in the base (capacity around 23 liters), Cutting Wheels: Dual 175mm,6.89" Diamond Double Cup, Worklight, Spanner Wrenches, Removable Splash Guards

Description:

The Agathon 175-DIA is a high-precision Swiss-made carbide tool grinding and lapping machine designed for sharpening turning, boring, and other tungsten carbide cutting tools

Electrics:

250V 3 Phase

Manufacturer: Agathon Model: 175-A
Main Unit Approx Weight: 660.00 lbs
Main Unit Dimensions (in inches): Length: 36.00"  Width: 25.00"  Height: 65.00"
Specs:
Wheel Size: 175mm" Diameter x .20mm Bore
Wheel Speed: 2500 RPM
Motor Horsepower: Drive Motor 1.5KW, Pump Motor 0.1KW
Clearance Angle Setting: 26-Degrees Max
Max Square Shank Tool Size: 40x40mm
Max Round Shank Tool Size: 16mm
Max Circular Form Tool: 35mm
Seller Company: Rock And Tools
Seller Contact: Machinesused.com October Multishop Phone: (763) 745-1166
Item Location: Rock And Tools, 2410 Niagara Lane N., Plymouth, MN 55447
Location Contact: Machinesused.com October Multishop Phone: (763) 745-1166
Inspection Date & Time: By Appointment Normal Business Hours Monday-Friday
Removal Dates and Times: This item must be removed between Wednesday, October 21, 2026 and Friday, October 30, 2026
