2004 ARBURG ALLROUNDER 470C 1500‐800 Injection Molding Machine

2004 ARBURG ALLROUNDER 470C 1500‐800 Injection Molding Machine

Name: 2004 ARBURG ALLROUNDER 470C 1500‐800 Injection Molding Machine
Brand: ARBURG
SKU: 81089412

Manufacturer

ARBURG

Spec Sheet

Clamp: 150 tons
Tie Bars: 470 × 470 mm
Platen Size: ~630 × 630 mm
Opening Stroke: ~500 mm
Daylight: ~850 mm

Injection Unit (800):

Screw: ~55 mm

Shot Size: ~27 oz

Shot Volume: ~800 cm³

Injection Pressure: ~17,000–18,500 psi

Controls: Selogica C‑Generation

Weight: ~18,000–20,000 lb

Buyer Is Responsible For Scheduling Transportation Of All Items, As Well As All Cost To Move It. We Can Provide You With Shipping And Rigging Quotes If You Need Help. Please Contact Us And We Will Assist You With Any Questions You May Have. All Items Are Sold "As Is, Where Is”. Specifications, Options, And Additional Accessories Are Quoted To The Best Of Our Knowledge And Are Subject To Buyer's Verification And Correction.
