1998 SNK Ikegai NB130P Horizontal Boring Mill (#4731)

Manufacturer

Category

Boring Mills

Stock

None

Model

None listed

Dealer Location

Florida

Spec Sheet



137.8" X 98.42" X 62.99" Horizontal Boring Mill with Fanuc 16im CNC Control, Built-in "B" Axis Rotary Table, Coolant Thru Spindle and Telescoping Way Covers Chip Conveyor

GENERAL SPECIFICATIONS
Spindle Diameter: 5.12"
X - Axis Travels: 137.8"
Y - Axis Travels: 98.42"
Z - Axis Travels: 62.99"
Rotary Table: 62.99" X 86.11"
Table Rotation: 360,000 Deg.
Table Load Capacity: 22,046 LBS
Spindle Motor: 35 HP
Spindle Taper: #50
Spindle Speed: Infinitely Variable - 3 Ranges 5 - 2,500 RPM
W - Axis (Spindle Travel): 27.55"
Tool Changer: 40 Position
Dimensions: 264" X 288" X 196"
Approx. Weight: 79,366 LBS

INCLUDES: Fanuc 16Im CNC Control, Built-in "B" Axis Rotary Table, Coolant Thru Spindle and Telescoping Way Covers Chip Conveyor


***We strongly encourage personal inspection of all pieces of used equipment***
***All Price, Location and Specifications Subject to Change without Notice***
