2022 Doosan DBM 2030 CNC Double Column Bridge Mill For Sale

Manufacturer

DOOSAN

Category

Machining Centers

Type

MACHINING CENTERS, GANTRY TYPE, CNC

Stock

MD74414

Model

DBM 2030

Dealer Location

Michigan

Request a Quote
View Contact Information

Spec Sheet

CNC Control - yes
Type of CNC Control - Fanuc 31i-B
Table Size - 118.1" x 59.1"
Max Table Load - 33069 lbs
X-Axis Travel - 128 inches
Y-Axis Travel - 98.4 inches
Z-Axis Travel - 31.5 inches
Spindle Taper - CAT 50 Big Plus
Spindle Speed - 8,000 rpm
Spindle Motor (HP) - 50 hp
ATC Capacity - 40 Stations
Machine Dimensions - 347" x 265" x 225"
Machine Weight - 77200 pounds


- Fanuc 31i-B CNC Control
- Coolant Tank & Pumps
- Coolant Thru Spindle (290 psi)
- Dual Z-axis Ballscrews
- Doosan Tool Load Monitoring
- Renishaw Probing Ready (RMI-Q Receiver)
- 5 Face Machining Support

** The DBM series is a multi-purpose double column machining center without W-axis
for applications such as heavy duty machining of large parts and high precision dies and molds
