2005 Nakamura WTW-150 CNC Lathe For Sale

Manufacturer

NAKAMURA-TOME

Category

Lathes

Type

LATHES, COMBINATION, CNC, (3-Axis Or More)

Stock

15047

Model

WTW-150

Dealer Location

Michigan

Request a Quote
View Contact Information

Spec Sheet

CNC Control - yes
Type of CNC Control - Fanuc 18i-TB
Turning Diameter - 12.2 inches
Center Distance - 41 inches
Chuck Size - 6 inches
Bar Capacity - 2.56 inches
X Axis Travel - 8.17 inches
Y Axis Travel - +/- 1.18" (2.36")
Z Axis Travel - 11.81 inches
B Axis Travel (Sub Spindle) - 34.44 inches
C Axis Index - 0.001°
Spindle Speed - 4,000 rpm
Main Motor - 20 hp
Tailstock - no
Y Axis - yes
Live Tooling - yes
Live Tooling Speed - 6,000 rpm
Live Tooling Motor - 4.3 hp
Sub Spindle - yes
Sub Spindle Chuck - 6 inches
Sub Spindle Bar Capacity - 2 inches
Sub Spindle Speed - 5,000 rpm
Sub Spindle Motor (HP) - 10 hp
Turret Capacity - Upper Turret - 24/24
Turret Capacity - Lower Turrets - 24/24
Machine Weight - 25000 pounds


- Dual Fanuc 18i-TB CNC Controls
- Upper Turrets
  • 24 Indexing Stations/ea - Static Only
  • 12 Live Tooling Stations
- Lower Turrets
  • 24 Indexing Stations/ea - Static Only
  • 12 Live Tooling Stations
- Y Axis on Upper Turrets Only
- Parts Catcher
- High Pressure Coolant
- Chip Conveyor
- Bar Feeder Interface
