2022 GMC HBR-0425 Hydraulic Plate Roll #8145 #1

Manufacturer

GMC

Category

Rolls

Type

ROLLS, PLATE BENDING, INIT & DBL PINCH TYPE, (Incl Sheet Metal)

Stock

8145

Model

HBR-0425

Dealer Location

California

Request a Quote
Login to Access Additional Features
View Contact Information

Spec Sheet

Overview

Type:
ROLLS, PLATE BEND'G,INIT.& DBL.PINCH TYPE
Manufacturer:
GMC
Model:
HBR-0425
Stock #:
8145
Status:
For Sale
Country:
United States

Description

GMC HBR-0425 Hydraulic Plate Roll, manufactured by GMC. This used model is ideal for plate bending with initial and double pinch capabilities. Suitable for various industrial applications.

2022 GMC HBR-0425 Hydraulic Plate Roll #8145 #1

SPECIFICATIONS:
Roll Capacity
Mild Steel: 4' x 1/4"
Stainless Steel: 4' x 3/16"
Soft Aluminum: 4' x 3/8"
Miniumum Thickness to Roll: 22 Ga.
Minimum Roll Diameter: 8"
Rolls Length: 4' 3"
Rolls Dia.: 6"
Pre-Bend: 0.18"
Roll Speed: 5 RPM
Rolls Opening: 2 1/2"
Oil Tank Cap.: 12 Gal.
Main Motor: 3 HP, 220V/ 10A
Weight: 4,150 lbs.
Dimensions: 87" x 36" x 53"
