600 TON CONTEMPORARY COMBO MOUNT / DISMOUNT WHEEL PRESS: STOCK# 57418

Manufacturer

Category

Presses

Type

PRESSES, WHEEL, HYDRAULIC

Stock

57418

Model

0600

Dealer Location

Ohio

Request a Quote
View Contact Information

Spec Sheet



CAPACITY ..................................... 600 TONS PRESSING
YEAR OF MANUFACTURE...........................  1993
SPEED RANGE ......................... 0 - 14 IPM
RAPID APPROACH/RETRACT ....................... 85 / 150 IPM
MAIN RAM DIAMETER ............................ 22"
MAIN RAM WORKING TRAVEL ...................... 36" EACH
TENSION BAR CROSS SECTION .................... 4 X 12"
MOVABLE STRONG BACK CAPACITY DIAMETER......... 24"
DISTANCE BETWEEN TENSION BARS ................ 54"
HORIZONTAL OFFSET OF TENSION BARS (INCLINE) .. 12"
MIN / MAX AXLE LENGTH ........................ 1 65 / 110"
MIN / MAX WHEEL DIAMETER ..................... 1 24 / 50"
ELECTRICAL POWER REQ ......................... 45K W
