2013 Nakamura Tome Super NTMX Multi-Tasking CNC Lathe For Sale

Stock

15288

Model

Super NTMX

Dealer Location

Michigan

Spec Sheet

CNC Control - yes
Type of CNC Control - Fanuc Series 31-Model A5
# Axis - 9
Turning Diameter - 7.87 inches
Center Distance - 30.7 inches
Chuck Size - 6 inches
Bar Capacity - 2 inches
X Axis Travel - 22.44 inches
Z Axis Travel - 51.06 inches
X2 Axis Travel - 5.13 inches
Z2 Axis Travel - 25.9 inches
Y Axis Travel - 7.86 inches
B Axis Travel (Sub Spindle) - 30.3 inches
B Axis Indexing - 190°
C1/C2 Axis Index - 0.001°
Spindle Nose - A2-5
Spindle Speed - 5,000 rpm
Main Motor - 15 hp
Tailstock - no
Y Axis - yes
Live Tooling - yes
Live Tooling Speed - 12,000 rpm - Milling Spindle
Live Tooling Motor - 10 hp
Sub Spindle Chuck - 6 inches
Sub Spindle Nose - A2-5
Sub Spindle Speed - 5,000 rpm
Sub Spindle Motor (HP) - 15 hp
Turret Capacity - 24
